পণ্যের বিবরণ:
|
| Resolution: | 0.1mm | Measuring Range: | 0.75～300mm (in Steel) |
|---|---|---|---|
| সঠিকতা: | ±(0.5% বেধ + 0.04) মিমি, উপাদান এবং অবস্থার উপর নির্ভর করে | Display: | 4.5 Digits LCD With EL Backlight |
| Sound Velocity Range: | 1000~9999 M/s | Units: | Metric/Imperial Unit Selectab |
| লক্ষণীয় করা: | Thorough Testing Equipment,Accurate Non Destructive Testing Equipment,Accurate Testing Equipment |
||
1.Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
2.Transducer models are available for special application, including for coarse grain material and high temperature applications.
3.Two-Point Calibration function.
4.Two work modes: Single point mode and Scan mode.
5.Coupling status indicator showing the coupling status.
6.Auto sleep and auto power off function to conserve battery li
| Parameter | Description |
|---|---|
| Accuracy | ±(0.5%Thickness+0.04)mm, Depends On Materials And Conditions |
| Display | 4.5 Digits LCD With EL Backlight |
| Resolution | 0.1mm |
| Units | Metric/Imperial Unit Selectable |
| Measuring Range | 0.75～300mm (in Steel) |
| Sound Velocity Range | 1000~9999 M/s |
Specifications
1.Display: 4.5 digits LCD with EL backlight.
2.Measuring Range:0.75～300mm (in Steel).
3.Sound Velocity Range: 1000~9999 m/s.
4.Resolution: 0.1mm.
5.Accuracy: ±(0.5%Thickness+0.04)mm, depends on materials and conditions
6.Units:Metric/Imperial unit selectable.
7.Four measurements readings per second for single point measurement, and ten per second for Scan Mode.
8.Memory for up to 20 files (up to 99 values for each file) of stored values.
9.Power Source:Two “AA” size, 1.5 Volt alkaline batteries. 100 hours typical operating time (EL backlight off).
10.Outline dimensions:150×74×32 mm. Weight
