Bandwidth
|
0.1MHz～20MHz
|
|
Gain
|
120dB, pace 0.1dB, 0.6dB, 1dB, 2dB, 6dB
|
|
Wave filter
|
Broadband, 1M, 1.25M, 2.5M, 5M, 10M, 15M, 1M-5M
|
|
Sampling rate
|
Hardware sampling rate 100MSPS, equivalent sampling rate 400MSPS
|
|
Detection mode
|
Full wave, positive half wave, negative half wave, RF, envelope
|
|
Detection range
|
10m (longitudinal wave carbon steel) , pace 100mm,10mm,0.1mm
|
|
Pulse mode
|
Sharp pulse, square wave, dual-square wave
|
|
Pulse voltage
|
25V～300V Stepping 25V
|
|
Pulse width
|
0ns～500ns continuously adjustable, 5ns pace
|
|
Damping
|
Strong (100Ω) ,weak (1000Ω) adjustable
|
|
Pulse repetition
frequency
|
Automatic or manual, auto Scope (200Hz-1KHz), manual scope (0-10KHz)
|
|
Probe channel
|
200 groups, supporting operations such as creating, previewing, deleting, renaming, overwriting, and restoring
|
|
Gate alarm
|
Gate A and B alarm, lost wave/incoming wave
|
|
Gate mode
|
Independent gate A, gate B
|
|
Measurement mode
|
Peak, Front edge, J Front edge
|
|
Quantitative mode
|
DAC curve, AVG(DGS) curve
|
|
Flaw detection
standards
|
AWS D1.1/D1.5, NB/T 47013, GB/T 29712, GB/T 11345
|
|
Save content
|
Single-frame, multi-frame recording (≤500 frames), screenshots, B-scan screenshots
|
|
Auxiliary functions
|
automatic gain, peak memory, waveform freezing, channel management, gate
alarm, gate expansion, automatic gate, full screen touch, virtual keyboard, color half span, quick screenshot
|
|
Display screen
|
High definition 5.0-inch 800×480 LCD, IPS_LCD
|
|
Probe interface
|
Dual LEMO-00
|
|
Output interface
|
Type-C1, MINI USB
|
|
B-scan imaging
|
support up to 700 groups of A-scan synthesis, and the highest resolution is φ2mm
|
|
Data storage
|
8GB SD card
|
|
Charger
|
PD fast charging, standard Type-C interface(100～240V, 50～60Hz)
|
|
Size
|
183mm×113mm×45mm
|
|
Weight
|
700g, includes battery without rubber boot
|
|
Language
|
English
|
|
Unit
|
Metric,imperial
|
|
Battery
|
7.4V 8000mAh Lithium battery, 12 hours of battery life
|
|
Operating temperature
|
-10℃～55℃
|
|
Resolution
|
40dB (Metrological performance requirements:≥26dB)
|
|
Dynamic range
|
32dB (Metrological performance requirements:≥26dB)
|
|
Sensitivity margin
|
50dB (Metrological performance requirements:≥42dB)
|
|
Vertical linearity
|
1.8% (Metrological performance requirements:≤6%)
|
|
Horizontal
linearity
|
0.5% (Metrological performance requirements:≤2%)
|
